ImageEn, unit iexBitmaps

TIOParams.JPEG_Quality

TIOParams.JPEG_Quality


Declaration

property JPEG_Quality: integer;


Description

The quality factor for the current JPEG image. Range is 1 to 100, though typical range is 60 (low quality) to 95 (high quality).
Higher values will improve image quality but require more disk space.

Notes:
- This property is not stored in a JPEG image, so it is never set when loading an image. Instead you set it when saving a JPEG to specify your desired compression
- It is possible to estimate the original JPEG compression using IECalcJpegStreamQuality or IECalcJpegFileQuality
- For TIFF files with ioTIFF_JPEG compression, specify JPEG quality using TIFF_JPEGQuality
- For DICOM files with iedcJPEG compression, specify JPEG quality using DICOM_JPEGQuality

Default: 80 (Specified by IOParamDefaults)


Quality Comparison

// Test Code
var
  i, qual: Integer;
  bmp: TIEBitmap;
begin
  for i := 1 to 20 do
  begin
    qual := i * 5;
    bmp := TIEBitmap.Create;
    bmp.ParamsEnabled := True;
    bmp.Read( TestFilename );
    bmp.Params.JPEG_Quality := qual;
    bmp.Write( 'Test_'+IntToStr( qual )+'.jpg' );
    bmp.Free;

    bmp := TIEBitmap.Create;
    bmp.Read( 'Test_'+IntToStr( qual )+'.jpg' );
    bmp.Resample( 2.0 );
    bmp.Crop( MulDiv( bmp.Width, 1, 4 ), MulDiv( bmp.Height, 1, 4 ), MulDiv( bmp.Width, 3, 4 ), MulDiv( bmp.Height, 3, 4 ));
    bmp.Write( '_'+IntToStr( qual )+'.png' );
    bmp.Free;
  end;
end;



Quality Value Size Reduction Sample Zoomed to 200%
Original 146 KB -
100 74 KB 50%
95 37 KB 75%
90 26 KB 82%
85 21 KB 86%
80 18 KB 88%
75 16 KB 89%
70 14 KB 90%
65 13 KB 91%
60 12 KB 92%
55 11 KB 92%
50 11 KB 93%
45 10 KB 93%
40 9 KB 94%
35 9 KB 94%
30 8 KB 95%
25 7 KB 95%
20 6 KB 96%
15 5 KB 96%
10 4 KB 97%
5 3 KB 98%



Quality Value Size Reduction Sample Zoomed to 200%
Original 113 KB -
100 55 KB 52%
95 25 KB 78%
90 18 KB 84%
85 14 KB 88%
80 12 KB 89%
75 11 KB 91%
70 10 KB 91%
65 9 KB 92%
60 8 KB 93%
55 8 KB 93%
50 7 KB 93%
45 7 KB 94%
40 7 KB 94%
35 6 KB 95%
30 6 KB 95%
25 5 KB 95%
20 5 KB 96%
15 4 KB 96%
10 4 KB 97%
5 3 KB 97%


Examples

// Load a JPEG and save it using the same compression quality
ImageEnView1.IO.LoadFromFile('C:\input.jpg');
ImageEnView1.IO.Params.JPEG_Quality := IECalcJpegFileQuality('C:\input.jpg');
ImageEnView1.IO.SaveToFile('D:\output.jpg');

// Convert a BMP to a JPEG at 90% quality
bmp := TIEBitmap.create;
bmp.ParamsEnabled := True;
bmp.Read( 'D:\input.bmp' );
bmp.Params.JPEG_Quality := 90;
bmp.Write( 'D:\output.jpg' );
bmp.Free;


See Also

- TIFF_JPEGQuality
- DICOM_JPEGQuality
