ImageEn, unit imageenproc

TImageEnProc.ApplyFilter

TImageEnProc.ApplyFilter


Declaration

procedure ApplyFilter(filter: TGraphFilter);


Description

Apply a 3x3 filter to the current image (or the selected region).

Note:
 A UI for this is available to your users in the Image Processing dialog
 If the image PixelFormat is not ie24RGB, it will be converted


Example

// Apply emboss filter
Const
  filter: TGraphFilter = ( Values: ( (-1, 0, 1), (-1, 1, 1), (-1, 0, 1) ); Divisor: 1 );
Begin
  ImageEnView1.Proc.ApplyFilter(filter);
End;
