procedure TMainForm.ButtonAddInputClick(Sender: TObject);
var
  ie: TImageEnView;
  iVideoInput: Integer;
  iVideoSource: Integer;
begin
  ie := TImageEnView.Create(self);
  ie.Parent := self;
  ie.Visible := false;
  ie.OnDShowNewFrame := NewFrame;
  FormSelectInput.ie := ie;
  if FormSelectInput.ShowModal = mrOK then
  begin
    FImageEnViews.Add(ie);
    iVideoInput  := FormSelectInput.ComboBoxVideoInput.ItemIndex;
    iVideoSource := StrToIntDef(FormSelectInput.EditVideoSource.Text, 0);
    ie.IO.DShowParams.SetVideoInput(iVideoInput, iVideoSource);
    ie.IO.DShowParams.EnableSampleGrabber := true;
    ie.IO.DShowParams.Connect;
    ie.IO.DShowParams.Run;
    ie.Tag := ImageEnMView1.AppendImage(100, 100);
    ImageEnMView1.ImageTag[ie.Tag] := 1000 * iVideoInput + iVideoSource;
  end
  else
    ie.Free();
end;

procedure TMainForm.ImageEnMView1Click(Sender: TObject);
var
  iVideoInput: Integer;
  iVideoSource: Integer;
begin
  iSelected := ImageEnMView1.SelectedImage;
  if iSelected < 0 then
  begin
    ieDisplay.IO.DShowParams.Stop;
    ieDisplay.Blank;
  end
  else
  begin
    iVideoInput  := ImageEnMView1.ImageTag[iSelected] div 1000;
    iVideoSource := ImageEnMView1.ImageTag[iSelected] mod 1000;
    ie.IO.DShowParams.SetVideoInput(iVideoInput, iVideoSource);
    ieDisplay.IO.DShowParams.EnableSampleGrabber := true;
    ieDisplay.IO.DShowParams.Connect;
    ieDisplay.IO.DShowParams.Run;
  end;
end;

unit umain;

interface

uses
  Windows, Messages, SysUtils, Variants, Classes, Graphics, Controls, Forms,
  Dialogs, StdCtrls, imageenview, ieview, iemview, XPMan, Buttons, ExtCtrls,
  ComCtrls, ieds;

type
  TMainForm = class(TForm)
    XPManifest1: TXPManifest;
    Panel1: TPanel;
    ButtonAddInput: TBitBtn;
    StatusBar1: TStatusBar;
    Panel3: TPanel;
    Panel4: TPanel;
    ImageEnMView1: TImageEnMView;
    Panel5: TPanel;
    Splitter1: TSplitter;
    ImageEnView1: TImageEnView;
    Panel2: TPanel;
    Panel6: TPanel;
    procedure ButtonAddInputClick(Sender: TObject);
    procedure FormCreate(Sender: TObject);
    procedure FormDestroy(Sender: TObject);
    procedure ImageEnMView1Click(Sender: TObject);

private
    { Private declarations }
    FImageEnViews: TList;
  public
    { Public declarations }

  procedure NewFrame(Sender: TObject);

  end;

var
  MainForm: TMainForm;

  ie: TImageEnView;

implementation

uses uselectinput;

{$R *.dfm}


procedure TMainForm.NewFrame(Sender: TObject);
var
  ie: TImageEnView;
  idx: integer;
begin
  ie := Sender as TImageEnView;
  idx := ie.Tag;
  ie.IO.DShowParams.GetSample(ImageEnMView1.GetTIEBitmap(idx));
  ImageEnMView1.ReleaseBitmap(idx);
  ImageEnMView1.UpdateImage(idx);

end;


procedure TMainForm.ButtonAddInputClick(Sender: TObject);
var
  iVideoInput: Integer;
  iVideoSource: Integer;

begin
  ie := TImageEnView.Create(self);
  ie.Parent := self;
  ie.Visible := false;
  ie.OnDShowNewFrame := NewFrame;
  FormSelectInput.ie := ie;
  if FormSelectInput.ShowModal = mrOK then
  begin
    FImageEnViews.Add(ie);
    iVideoInput  := FormSelectInput.ComboBoxVideoInput.ItemIndex;
    iVideoSource := StrToIntDef(FormSelectInput.EditVideoSource.Text, 0);
    ie.IO.DShowParams.SetVideoInput(iVideoInput, iVideoSource);
    ie.IO.DShowParams.EnableSampleGrabber := true;
    ie.IO.DShowParams.Connect;
    ie.IO.DShowParams.Run;
    ie.Tag := ImageEnMView1.AppendImage(100, 100);

     ImageEnMView1.ImageTag[ie.Tag] := 1000 * iVideoInput + iVideoSource;
  end
  else
    ie.Free();
end;


procedure TMainForm.FormCreate(Sender: TObject);
begin
  FImageEnViews := TList.Create();
end;

procedure TMainForm.FormDestroy(Sender: TObject);
var
  i: integer;
begin
  for i := 0 to FImageEnViews.Count - 1 do
    (TObject(FImageEnViews[i]) as TImageEnView).Free();
end;


procedure TMainForm.ImageEnMView1Click(Sender: TObject);
var
  iVideoInput: Integer;
  iVideoSource: Integer;
  iSelected: Integer;

begin
  iSelected := ImageEnMView1.SelectedImage;
  if iSelected < 0 then
  begin
    ImageEnView1.IO.DShowParams.Stop;
    ImageEnView1.Blank;
  end
  else
  begin
    iVideoInput  := ImageEnMView1.ImageTag[iSelected] div 1000;
    iVideoSource := ImageEnMView1.ImageTag[iSelected] mod 1000;
    ie.IO.DShowParams.SetVideoInput(iVideoInput, iVideoSource);
    ImageEnView1.IO.DShowParams.EnableSampleGrabber := true;
    ImageEnView1.IO.DShowParams.Connect;
    ImageEnView1.IO.DShowParams.Run;

  end;

end;

end.

procedure Tfmain.ieDisplayDShowNewFrame(Sender: TObject);
begin
  // copy current sample to ImageEnView's bitmap
  ieDisplay.IO.DShowParams.GetSample(ImageEnView1.Layers[0].Bitmap);

  // refresh the view
  ieDisplay.Update;
end;
