object Form1: TForm1
  Left = 0
  Top = 0
  Caption = 'TIFFHandler'
  ClientHeight = 299
  ClientWidth = 635
  Color = clBtnFace
  Font.Charset = DEFAULT_CHARSET
  Font.Color = clWindowText
  Font.Height = -11
  Font.Name = 'Tahoma'
  Font.Style = []
  OldCreateOrder = False
  OnCreate = FormCreate
  OnDestroy = FormDestroy
  PixelsPerInch = 96
  TextHeight = 13
  object Splitter1: TSplitter
    Left = 203
    Top = 41
    Width = 5
    Height = 198
    ResizeStyle = rsUpdate
    ExplicitLeft = 180
  end
  object Panel1: TPanel
    Left = 0
    Top = 0
    Width = 635
    Height = 41
    Align = alTop
    BevelOuter = bvNone
    TabOrder = 0
    DesignSize = (
      635
      41)
    object Close1: TButton
      Left = 549
      Top = 7
      Width = 75
      Height = 25
      Anchors = [akTop, akRight]
      Caption = 'Close'
      TabOrder = 0
      OnClick = Close1Click
    end
    object Open1: TButton
      Left = 12
      Top = 10
      Width = 75
      Height = 25
      Caption = 'Open'
      TabOrder = 1
      OnClick = Open1Click
    end
    object Save1: TButton
      Left = 93
      Top = 10
      Width = 75
      Height = 25
      Caption = 'Save'
      TabOrder = 2
      OnClick = Save1Click
    end
    object SaveAs1: TButton
      Left = 174
      Top = 10
      Width = 75
      Height = 25
      Caption = 'SaveAs'
      TabOrder = 3
      OnClick = SaveAs1Click
    end
    object Rotate1: TButton
      Left = 255
      Top = 10
      Width = 75
      Height = 25
      Caption = 'Rotate'
      TabOrder = 4
      OnClick = Rotate1Click
    end
  end
  object Panel2: TPanel
    Left = 0
    Top = 239
    Width = 635
    Height = 41
    Align = alBottom
    BevelOuter = bvNone
    TabOrder = 1
    DesignSize = (
      635
      41)
    object Close2: TButton
      Left = 549
      Top = 8
      Width = 75
      Height = 25
      Anchors = [akTop, akRight]
      Caption = 'Close'
      TabOrder = 0
      OnClick = Close1Click
    end
  end
  object StatusBar1: TStatusBar
    Left = 0
    Top = 280
    Width = 635
    Height = 19
    Panels = <>
  end
  object ImageEnMView1: TImageEnMView
    Left = 0
    Top = 41
    Width = 203
    Height = 198
    Background = clBtnFace
    ParentCtl3D = False
    StoreType = ietNormal
    ThumbWidth = 100
    ThumbHeight = 100
    HorizBorder = 4
    VertBorder = 4
    TextMargin = 0
    OnImageSelect = ImageEnMView1ImageSelect
    GridWidth = 1
    Style = iemsACD
    ThumbnailsBackground = clBtnFace
    ThumbnailsBackgroundSelected = clBtnFace
    EnableMultiSelect = True
    MultiSelectionOptions = []
    ThumbnailsBorderWidth = 0
    Align = alLeft
    PopupMenu = PopupMenu1
    TabOrder = 3
  end
  object ImageEnView1: TImageEnView
    Left = 208
    Top = 41
    Width = 427
    Height = 198
    Background = clBtnFace
    ParentCtl3D = False
    EnableInteractionHints = True
    Align = alClient
    TabOrder = 4
  end
  object OpenPictureDialog1: TOpenPictureDialog
    Left = 12
    Top = 244
  end
  object SavePictureDialog1: TSavePictureDialog
    Left = 41
    Top = 245
  end
  object ImageEnProc1: TImageEnProc
    PreviewsParams = [prppShowResetButton, prppHardReset]
    PreviewFont.Charset = DEFAULT_CHARSET
    PreviewFont.Color = clWindowText
    PreviewFont.Height = -11
    PreviewFont.Name = 'Tahoma'
    PreviewFont.Style = []
    Left = 72
    Top = 246
  end
  object ImageEnIO1: TImageEnIO
    PreviewFont.Charset = DEFAULT_CHARSET
    PreviewFont.Color = clWindowText
    PreviewFont.Height = -11
    PreviewFont.Name = 'Tahoma'
    PreviewFont.Style = []
    Left = 101
    Top = 247
  end
  object ImageEnMIO1: TImageEnMIO
    PreviewFont.Charset = DEFAULT_CHARSET
    PreviewFont.Color = clWindowText
    PreviewFont.Height = -11
    PreviewFont.Name = 'Tahoma'
    PreviewFont.Style = []
    Left = 131
    Top = 247
  end
  object PopupMenu1: TPopupMenu
    Left = 160
    Top = 247
    object Delete1: TMenuItem
      Caption = 'Delete'
      OnClick = Delete1Click
    end
    object Rotate2: TMenuItem
      Caption = 'Rotate'
      OnClick = Rotate1Click
    end
  end
end

unit Unit1;

interface

uses
  Winapi.Windows, Winapi.Messages, System.SysUtils, System.Variants,
  System.Classes, Vcl.Graphics, Vcl.Controls, Vcl.Forms, Vcl.Dialogs,
  Vcl.ExtCtrls, Vcl.ExtDlgs, Vcl.StdCtrls, Vcl.ComCtrls,
  iemio, imageenio, imageenproc, hyiedefs, hyieutils, imageenview, ieview,
  iemview, Vcl.Menus;

type
  TForm1 = class(TForm)
    Panel1: TPanel;
    Panel2: TPanel;
    StatusBar1: TStatusBar;
    Close1: TButton;
    Close2: TButton;
    OpenPictureDialog1: TOpenPictureDialog;
    SavePictureDialog1: TSavePictureDialog;
    Open1: TButton;
    Save1: TButton;
    SaveAs1: TButton;
    ImageEnMView1: TImageEnMView;
    Splitter1: TSplitter;
    ImageEnView1: TImageEnView;
    ImageEnProc1: TImageEnProc;
    ImageEnIO1: TImageEnIO;
    ImageEnMIO1: TImageEnMIO;
    Rotate1: TButton;
    PopupMenu1: TPopupMenu;
    Delete1: TMenuItem;
    Rotate2: TMenuItem;
    procedure FormCreate(Sender: TObject);
    procedure FormDestroy(Sender: TObject);
    procedure Open1Click(Sender: TObject);
    procedure SaveAs1Click(Sender: TObject);
    procedure Close1Click(Sender: TObject);
    procedure ImageEnMView1ImageSelect(Sender: TObject; idx: Integer);
    procedure Rotate1Click(Sender: TObject);
    procedure Delete1Click(Sender: TObject);
    procedure Save1Click(Sender: TObject);
  private
    { Private declarations }
    AFilename: string;
  public
    { Public declarations }
  end;

var
  Form1: TForm1;

implementation

{$R *.dfm}

procedure TForm1.Close1Click(Sender: TObject);
begin
  Close;
end;

procedure TForm1.Delete1Click(Sender: TObject);
var
  i: Integer;
begin
  for i := 0 to ImageEnMView1.MultiSelectedImagesCount - 1 do
  begin
    ImageEnMView1.DeleteImage(i);
  end;
end;

procedure TForm1.FormCreate(Sender: TObject);
begin
  AFilename := '';
  IERegisterFormats;
  OpenPictureDialog1.Filter := GraphicFilter(TGraphic);
  SavePictureDialog1.Filter := GraphicFilter(TGraphic);
  ImageEnMView1.SetModernStyling(True, 150, 100);
  ATIFHandler := TIETIFFHandler.Create;
end;

procedure TForm1.FormDestroy(Sender: TObject);
begin
  IEUnRegisterFormats;
end;

procedure TForm1.ImageEnMView1ImageSelect(Sender: TObject; idx: Integer);
var
  iIEBitmap: TIEBitmap;
begin
  iIEBitmap := ImageEnMView1.GetTIEBitmap(idx);
  try
    ImageEnView1.IEBitmap.Assign(iIEBitmap);
    ImageEnView1.Update;
  finally
    ImageEnMView1.ReleaseBitmap(idx);
  end;
end;

procedure TForm1.Open1Click(Sender: TObject);
begin
  OpenPictureDialog1.DefaultExt := '.tif';
  if OpenPictureDialog1.Execute then
  begin
    if FileExists(OpenPictureDialog1.FileName) then
    begin
      AFilename := OpenPictureDialog1.FileName;
      ImageEnMView1.MIO.LoadFromFile(AFilename);
      Caption := 'TIFFHandler- ' + AFilename;
    end;
  end;
end;

procedure TForm1.Rotate1Click(Sender: TObject);
var
  iIndex: Integer;
  iIEBitmap: TIEBitmap;
begin
  iIndex := ImageEnMView1.SelectedImage;
  ImageEnMView1.Proc.Rotate(90);
  iIEBitmap := ImageEnMView1.GetTIEBitmap(iIndex);
  try
    ImageEnView1.IEBitmap.Assign(iIEBitmap);
    ImageEnView1.Update;
  finally
    ImageEnMView1.ReleaseBitmap(iIndex);
  end;
end;

procedure TForm1.Save1Click(Sender: TObject);
begin
  if FileExists(AFilename) then
    ImageEnMView1.MIO.SaveToFile(AFilename);
end;

procedure TForm1.SaveAs1Click(Sender: TObject);
begin
  SavePictureDialog1.DefaultExt := '.tif';
  if SavePictureDialog1.Execute then
  begin
    AFilename := SavePictureDialog1.FileName;
    ImageEnMView1.MIO.SaveToFile(AFilename);
    Caption := 'TIFFHandler- ' + AFilename;
  end;
end;

end.

procedure TForm1.ImageEnMView1ImageSelect(Sender: TObject; Idx: Integer);
{ Display the image in ImageEnView. }
var
  iFilename: string;
begin
  if Idx <> -1 then
  begin
    ImageEnView1.IO.LoadFromFileJpeg(ImageEnMView1.MIO.Params[Idx].FileName);
    { Get the filename from the thumbnail }
    iFilename := ImageEnMView1.MIO.Params[iIndex].FileName;
    ImageEnView1.IO.LoadFromFile(iFilename);
   end;
end;
