 Acquire with TWAIN not running on this case		  New Topic  Reply to Topic
Author Previous Topic Topic Next Topic

Dany

67 Posts
Posted - Aug 27 2018 :  15:41:23  Show Profile  Reply
Hello;

In some way, this is related to a previos post I sent today. On one PC I have read for TWIAN sources, getting one TWAIN and one WIA for the same scanner. When I try to use the TWAIN one, MIO.Acquire stops the application and I have to kill it with task manager. And on the task manager I can't see any TWAIN running. But if I chose the same device with PDF24, it works fine, and also I can see it is opening a TWAIN process in the task manager. Pease see the attached images.

Is it something I missed? Thank you very much!.

xequte

39141 Posts
Posted - Aug 27 2018 :  18:07:53  Show Profile  Reply
Hi

Please try reproducing this with the AllAcquire demo and send us the log file.

Nigel
Xequte Software
www.imageen.com
Go to Top of Page

Dany

67 Posts
Posted - Aug 28 2018 :  08:29:38  Show Profile  Reply
Twain log. Core version 8.0.1 9 7 2018
28/08/2018 9:19:59 : CreateProxyWindow
28/08/2018 9:19:59 : CreateProxyWindow : created
28/08/2018 9:19:59 : IETW_LoadSourceManager
28/08/2018 9:19:59 : IETW_LoadSourceManager : Load OK
28/08/2018 9:19:59 : IETW_OpenSourceManager
28/08/2018 9:19:59 : IETW_OpenSourceManager : Ok
28/08/2018 9:19:59 : IETW_CloseSourceManager
28/08/2018 9:19:59 : IETW_EmptyMessageQueue
28/08/2018 9:19:59 : IETW_EmptyMessageQueue : end
28/08/2018 9:19:59 : IETW_CloseSourceManager : Ok
28/08/2018 9:19:59 : IETW_UnloadSourceManager
28/08/2018 9:19:59 : IETW_UnloadSourceManager not Unloaded, for future uses
28/08/2018 9:19:59 : DestroyProxyWindow
28/08/2018 9:19:59 : DestroyProxyWindow : not destroyed, for future uses
28/08/2018 9:19:59 : CreateProxyWindow
28/08/2018 9:19:59 : CreateProxyWindow : already created
28/08/2018 9:19:59 : IETW_LoadSourceManager
28/08/2018 9:19:59 : IETW_LoadSourceManager : already loaded
28/08/2018 9:19:59 : IETW_OpenSourceManager
28/08/2018 9:19:59 : IETW_OpenSourceManager : Ok
28/08/2018 9:19:59 : IETW_OpenSource
28/08/2018 9:19:59 : Opening "HP LaserJet M1005 MFP TWAIN"
28/08/2018 9:19:59 : Success opening name:"HP LaserJet M1005 MFP TWAIN" ver:"Versión 1.0.0.2 4/ 1/2013" twain:1.9
28/08/2018 9:19:59 : GetCapability : $0102
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetUINT16asInteger
28/08/2018 9:19:59 : GetUINT16asInteger : ok
28/08/2018 9:19:59 : GetCapability : $1118
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetFix32asDouble
28/08/2018 9:19:59 : GetFix32asDouble : ok
28/08/2018 9:19:59 : GetCapability : $1119
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetFix32asDouble
28/08/2018 9:19:59 : GetFix32asDouble : ok
28/08/2018 9:19:59 : GetCapability : $1124
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetFix32asDouble
28/08/2018 9:19:59 : GetFix32asDouble : ok
28/08/2018 9:19:59 : GetCapability : $1125
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetFix32asDouble
28/08/2018 9:19:59 : GetFix32asDouble : ok
28/08/2018 9:19:59 : GetCapability : $1103
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1101
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetFix32asDouble
28/08/2018 9:19:59 : GetFix32asDouble : ok
28/08/2018 9:19:59 : GetCapability : $1123
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1121
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $0101
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetUINT16asInteger
28/08/2018 9:19:59 : GetUINT16asInteger : ok
28/08/2018 9:19:59 : GetCapability : $112B
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetUINT16asInteger
28/08/2018 9:19:59 : GetUINT16asInteger : ok
28/08/2018 9:19:59 : GetCapability : $1108
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1112
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetOnFIX32asDouble
28/08/2018 9:19:59 : GetOneFIX32asDouble : ok
28/08/2018 9:19:59 : GetCapability : $1111
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetOnFIX32asDouble
28/08/2018 9:19:59 : GetOneFIX32asDouble : ok
28/08/2018 9:19:59 : GetCapability : $1002
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetCapability : $1007
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1151
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1150
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1100
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1152
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1134
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1106
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $110A
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1113
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1010
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $100F
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetCapability : $0001
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : GetCapability : $1003
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $100D
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1013
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1012
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1110
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $1122
28/08/2018 9:19:59 : IETW_DS : General failure. Unload Source immediately.
28/08/2018 9:19:59 : GetCapability : FAILED!
28/08/2018 9:19:59 : GetCapability : $100B
28/08/2018 9:19:59 : GetCapability : Ok
28/08/2018 9:19:59 : IETW_CloseSource
28/08/2018 9:19:59 : IETW_CloseSource : Ok
28/08/2018 9:19:59 : IETW_CloseSourceManager
28/08/2018 9:19:59 : IETW_EmptyMessageQueue
28/08/2018 9:19:59 : IETW_EmptyMessageQueue : end
28/08/2018 9:19:59 : IETW_CloseSourceManager : Ok
28/08/2018 9:19:59 : IETW_UnloadSourceManager
28/08/2018 9:19:59 : IETW_UnloadSourceManager not Unloaded, for future uses
28/08/2018 9:19:59 : DestroyProxyWindow
28/08/2018 9:19:59 : DestroyProxyWindow : not destroyed, for future uses
28/08/2018 9:20:25 : IETW_LoadSourceManager
28/08/2018 9:20:25 : IETW_LoadSourceManager : already loaded
28/08/2018 9:20:25 : IETW_OpenSourceManager
28/08/2018 9:20:25 : IETW_OpenSourceManager : Ok
28/08/2018 9:20:28 : IETW_CloseSourceManager
28/08/2018 9:20:28 : IETW_EmptyMessageQueue
28/08/2018 9:20:28 : IETW_MessageHook
28/08/2018 9:20:28 : IETW_MessageHook : state = 3
28/08/2018 9:20:28 : IETW_EmptyMessageQueue : end
28/08/2018 9:20:28 : IETW_CloseSourceManager : Ok
28/08/2018 9:20:28 : IETW_UnloadSourceManager
28/08/2018 9:20:28 : IETW_UnloadSourceManager not Unloaded, for future uses
28/08/2018 9:20:38 : IETW_Acquire
28/08/2018 9:20:38 : CreateProxyWindow
28/08/2018 9:20:38 : CreateProxyWindow : already created
28/08/2018 9:20:38 : IETW_LoadSourceManager
28/08/2018 9:20:38 : IETW_LoadSourceManager : already loaded
28/08/2018 9:20:38 : IETW_OpenSourceManager
28/08/2018 9:20:38 : IETW_OpenSourceManager : Ok
28/08/2018 9:20:38 : IETW_OpenSource
28/08/2018 9:20:38 : Opening "HP LaserJet M1005 MFP TWAIN"
28/08/2018 9:20:38 : Success opening name:"HP LaserJet M1005 MFP TWAIN" ver:"Versión 1.0.0.2 4/ 1/2013" twain:1.9
28/08/2018 9:20:38 : IETW_SetCapabilities
28/08/2018 9:20:38 : IETW_SetCapabilities : ICAP_PIXELTYPE
28/08/2018 9:20:38 : GetCapability : $0101
28/08/2018 9:20:38 : GetCapability : Ok
28/08/2018 9:20:38 : SetIntegerAsUINT16Capability
28/08/2018 9:20:38 : SetIntegerAsUINT16Capability : ok
28/08/2018 9:20:38 : IETW_SetCapabilities : ICAP_UNITS
28/08/2018 9:20:38 : GetCapability : $0102
28/08/2018 9:20:38 : GetCapability : Ok
28/08/2018 9:20:38 : GetUINT16asInteger
28/08/2018 9:20:38 : GetUINT16asInteger : ok
28/08/2018 9:20:38 : IETW_SetCapabilities : ICAP_PIXELFLAVOR
28/08/2018 9:20:38 : GetCapability : $111F
28/08/2018 9:20:38 : GetCapability : Ok
28/08/2018 9:20:38 : SetOneUINT16Capability
28/08/2018 9:20:38 : IETW_DS : Exception -> Access violation at address 10013C48 in module 'agtwain.ds'. Read of address 00000000
28/08/2018 9:20:38 : SetOneUINT16Capability : FAILED!
28/08/2018 9:20:38 : GetCapability : $111F
Go to Top of Page

xequte

39141 Posts
Posted - Aug 29 2018 :  03:50:13  Show Profile  Reply
Hi

Unfortunately, I cannot see anything in particular here that would allow us to suggest a solution.

The driver is quite old (2013) and supports Twain 1.9, so it might be a compatibility issue. Unfortunately it is the last driver version released by HP...




Nigel
Xequte Software
www.imageen.com
Go to Top of Page

Dany

67 Posts
Posted - Aug 29 2018 :  07:31:15  Show Profile  Reply
But what I can't understand is why your procedure is not raising the error so I can un-frezee my application. Now the only solution is to shuting down my application by windows taskmanager!!!. BTW, please take in mind that PDF24 and Windows can use that driver and it is working for them.
Go to Top of Page

xequte

39141 Posts
Posted - Sep 04 2018 :  16:10:59  Show Profile  Reply
Hi Dany

It is freezing up in the driver (not returning to the application). We are currently investigating whether we can avoid this.



Nigel
Xequte Software
www.imageen.com
Go to Top of Page

Dany

67 Posts
Posted - Sep 12 2018 :  09:13:47  Show Profile  Reply
Thank you Nigel. What we see is, we can use this driver from other programs.

Dany
Go to Top of Page

xequte

39141 Posts
Posted - Sep 12 2018 :  15:27:31  Show Profile  Reply
Hi

Unfortunately we could not find a practical way to prevent ImageEn from freezing when a driver locks up.



Nigel
Xequte Software
www.imageen.com
Go to Top of Page
