| Author |
 Topic  |
|
|
Flashcqxg
93 Posts |
 Posted - Sep 26 2021 : 20:51:28
|
Is it normal to use the TextOut method of TImageEnProc to take about 240 milliseconds?
SW := TStopwatch.StartNew;
Proce.TextOut(50, 50, 'SS', 'Times New Roman', MarkTextFontSize, clRed, [fsBold]);
Memo1.Lines.Add(SW.ElapsedMilliseconds.ToString);
|
|
|
xequte
38180 Posts |
Posted - Sep 26 2021 : 21:05:14
|
Hi
TImageEnProc.TextOut actually uses GDI+ under the hood (for transparency and other features). The first time GDI+ is used it needs to be initialized which is slow, but subsequent calls should be much faster, for instance, when i tested your code five times, I got
200ms
1ms
1ms
<1ms
1ms
If you want to avoid this, use TCanvas.TextOut instead.
Nigel
Xequte Software
www.imageen.com
|
 |
|
|
Flashcqxg
93 Posts |
Posted - Sep 26 2021 : 21:23:08
|
Hi,my test:
procedure TForm1.Button1Click(Sender: TObject);
var
IO: TImageEnIO;
Proce: TImageEnProc;
I: Integer;
SW: TStopwatch;
begin
IO := TImageEnIO.Create(nil);
IO.Params.PDF_PaperWidth := 1190;
IO.Params.PDF_PaperHeight := 842;
Proce := TImageEnProc.CreateFromBitmap(IO.IEBitmap);
IO.LoadFromFileJpeg(ExtractFilePath(ParamStr(0)) + '1.JPEG');
try
for I := 1 to 10 do
begin
SW := TStopwatch.StartNew;
Proce.TextOut(50, 10 * I, 'SSS', 'Times New Roman', 35, clRed, [fsBold]);
Memo1.Lines.Add(SW.ElapsedMilliseconds.ToString);
end;
finally
IO.Free;
Proce.Free;
end;
end;
result:
294
267
267
268
268
265
267
268
270
267 |
|
|
|
xequte
38180 Posts |
Posted - Sep 27 2021 : 20:18:39
|
Hmmm, i cannot reproduce that.
249
20
20
20
21
21
21
21
21
21
What version of Delphi and Windows are you using? Is there any other code or ImageEn components in that test project?
Nigel
Xequte Software
www.imageen.com
|
|
|
|
Flashcqxg
93 Posts |
Posted - Sep 27 2021 : 22:53:32
|
No any other code or ImageEn components in this test project.
Delphi 10.3.2 and Windows 7 |
|
|
|
Flashcqxg
93 Posts |
Posted - Sep 27 2021 : 23:20:03
|
I found that the larger the picture, the slower the speed; the smaller the picture, the faster the speed. The image size I tested before was 3307*2339(316kb). Just now I tested a 4960*3508(588kb) image. The test results are as follows:
665
623
624
621
619
623
621
620
622
621 |
|
|
|
xequte
38180 Posts |
Posted - Sep 28 2021 : 23:19:19
|
Sorry, is this ImageEn 10.2.0?
Nigel
Xequte Software
www.imageen.com
|
|
|
|
Flashcqxg
93 Posts |
Posted - Sep 28 2021 : 23:22:08
|
| Yes,i test with delphi 10.3.3+windows7 + ImageEn 10.2 |
|
|
|
xequte
38180 Posts |
|
|
Flashcqxg
93 Posts |
Posted - Sep 28 2021 : 23:46:16
|
Project1_32
TEST 1...
298
279
283
278
280
280
281
279
278
281
TEST 2...
314
297
299
295
297
299
295
294
295
296
Project1_64:
TEST 1...
386
364
366
361
363
372
368
362
370
365
TEST 2...
393
380
384
383
383
396
384
381
385
384 |
|
|
|
xequte
38180 Posts |
Posted - Sep 29 2021 : 00:00:20
|
Hmm, it must be an issue in Windows 7. If you need to support Windows 7, you should use TCanvas.TextOut instead.
Nigel
Xequte Software
www.imageen.com
|
|
|
|
Flashcqxg
93 Posts |
Posted - Sep 29 2021 : 19:47:59
|
I don't think so, my test results on windows10 are as follows. You can use my test picture for testing, I uploaded it.
Memo1
TEST 1...
417
452
407
408
411
405
397
396
442
409
TEST 2...
414
401
466
378
346
349
339
332
359
374
 |
|
|
|
xequte
38180 Posts |
Posted - Sep 29 2021 : 21:25:42
|
Hi
Your image works here, though is a little slow. I will investigate the code some more.
TEST 1...
1780
200
196
196
196
199
197
195
199
197
TEST 2...
229
215
216
216
217
213
216
216
230
213
Nigel
Xequte Software
www.imageen.com
|
|
|
|
Flashcqxg
93 Posts |
Posted - Sep 29 2021 : 21:27:42
|
| Thank you, hope there is a good solution. |
|
|
|
xequte
38180 Posts |
Posted - Sep 29 2021 : 22:46:33
|
Hi
We've added extra checking and if the image has no alpha channel (like your image) then we can make it around 8x faster. Please email me for the update.
Nigel
Xequte Software
www.imageen.com
|
|
|
|
Flashcqxg
93 Posts |
Posted - Sep 29 2021 : 22:53:09
|
| This is good news. I will wait for the next version to be released before upgrading, thank you. |
|
|
| |
